Spray system

In a house with a width of less than 14 meters, there should be two rows of nozzles running through the house, two rows
The nozzle and the two walls divide the chicken house into three equal parts.

The working water volume of the low-pressure spray system is 7.6 litres/hour
• The nozzle on the spray line is installed at the center of each line of 3.1 meters, pointing straight down, two or two
Relatively staggered through the chicken coop.
• The spray line should form a circular line throughout the house.
• An automatic drain valve should be installed on each spray line to discharge water when the pump is turned off
Outside the chicken coop. The drain valve prevents dripping when the system is not working.
• In a chicken house with longitudinal ventilation, a distance of 1.2 meters along the air inlet is required.
Use a tee on both sides to add a spray line with a nozzle spacing of 1.5 meters; the water output is 7.6
L/h; 1.2 meters away from the air inlet.
• Use a 2 cm hose from the pump to the main spray line. The start and stop of the water pump is controlled by temperature and humidity
system

• The starting temperature of the sprayer is 28°C.
• The low-pressure spray system operates at a pressure of 7-14 bar, producing a size greater than 30 microns
Water droplets.
• The high-pressure spray system operates at a pressure of 28-41 bar, producing a size of 10-15 micrometers
Drops of rice.
When the airflow velocity exceeds 3.0 m/s, it must not be directly humidified onto the air inlet-air intake area
The nozzle should be placed in a position where the airflow speed is less than 3.0 m/s to prevent ground and chicken
Just get wet
